Plastering Mortar(bottom)Plant

Product Introduction

1. The main machine of the fully automatic dry powder mortar production line adopts a two-axis gravity-free mixer.

2. This machine is developed on the basis of integrating the technical essence of multiple generations of new models.

3. It has automatic feeding, pneumatic discharging, no accumulation of blocks on the barrel wall, and no dead ends Features.

4. All kinds of complete sets of dry powder mortar equipment produced by our company have the characteristics of small footprint, reasonable structure, simple operation, high production efficiency, no dust, reasonable power configuration, moderate investment, short construction period, and quick return on investment.

Advantages

1）Adopt new advanced reducer driving system instead of chain drive. save cost maintenance.

2）The paddle blades is removable type, convenient replacement of worn blades.

3）The blade is made of wear-resistant steel and is durable. Not ordinary steel plate cutting.

Applicable Materials

Also used for Masonry mortar，Plastering mortar(bottom)，Floor mortar，Caulking agent mortar(black)，Seaming agent mortar，Caulking agent mortar(white)，Seaming agent mortar，Thermal mortar，Self-leveling mortar，Whitewashed plaster(bottom)，Cement plaster mortar，External putty powder，etc.

Parameter

Model	Capacity (T/H)	Volume (m3)	Loading Coefficient/ Load factor	Rotary speed (r/min)	Mixing time  (min)	Storage of finished-product	Power (kW)	Size (mm)
WSZ2	10-15	2	0.4-0.6	43	Adjustable	Packing on bags of 5-50kg	18.5	2460 x 1640 x 1520
WSZ3	15-25	3	0.4-0.6	43	0.5-3	Packing on bags  of 5-50kg	22	2850 x 1640 x1520
WSZ4	25-40	4	0.4-0.6	29	0.5-3	Packing on bags of 10-50kg  and in bulk	30	2800 x 2110 x 1950
WSZ6	60-120	6	0.4-0.6	29	1.5-3	Packing on bags of 50kg and in bulk	45	3130 x 2470 x 2120
WSZ10	100-170	10	0.4-0.6	29	1.5-3	Packing on bags of 50kg and in bulk	55	3600 x 3000 x 2510
