Self-leveling mortar Plant

Product Introduction

Mini-type dry mortar mixing production line, which covers a small area, is cheap and easy to operate, is very suitable for small factories.

This solution includes 6 procedures:

Artificial feeding →lifting material → mixing →two lifting of materials → finished product storage→weighing and packaging;

1). Artificial feeding: manual feeding of raw materials and additives into the mouth;

2). To enhance the material: and then through a hoist to lift the material to the mixer;

3). Mixing: mixing machine for the full mixing of materials, about 5-10 minutes;

4). The two lifting material: after the completion of the material, through the two lift, transport to the finished goods warehouse;

5). Finished warehouse: finished warehouse after receiving material, storage;

6). Weighing and packaging: through the outlet of the finished warehouse packaging machine for automatic weighing and packaging.

Applicable Materials

Also used for Foundry sand，Crack Resistant Mortar，Plastering Mortar，Bonded Mortar，Decorative Mortar，Masonry Mortar，Gypsum Mortar.

Parameter

Model	Capacity (T/H)	Volume (m3)	Loading Coefficient/ Load factor	Rotary speed (r/min)	Mixing time  (min)	Storage of finished-product	Power (kW)	Size (mm)
WSZ2	10-15	2	0.4-0.6	43	Adjustable	Packing on bags of 5-50kg	18.5	2460 x 1640 x 1520
WSZ3	15-25	3	0.4-0.6	43	0.5-3	Packing on bags  of 5-50kg	22	2850 x 1640 x1520
WSZ4	25-40	4	0.4-0.6	29	0.5-3	Packing on bags of 10-50kg  and in bulk	30	2800 x 2110 x 1950
WSZ6	60-120	6	0.4-0.6	29	1.5-3	Packing on bags of 50kg and in bulk	45	3130 x 2470 x 2120
WSZ10	100-170	10	0.4-0.6	29	1.5-3	Packing on bags of 50kg and in bulk	55	3600 x 3000 x 2510
